Specification
The specifications, colors, parts, and availability of the products can be subjects to alter without prior notification.
Frameset
Frame
ALX XC TRAIL FRAME
Fork
ROCKSHOX RECON SILVER RL 120MM TRAVEL
Rear Shock
ROCKSHOX DELUXE SELECT PLUS E2E: 190x45MM
Frame Color
BITTER LEMON - BLACK
Decal Color
MUSTARD GREEN - DAVY GREY
Drivetrain
Shifter
SHIMANO DEORE SL-M5100, 11-SPEED TRIGGER
Crank
SHIMANO FC-M5100 SINGLE 32T TWO PIECE CRANK, 170MM (S,M) / 175MM (L,XL)
Cassette
SHIMANO DEORE CS-M5100 11-51T 11-SPEED
Rear Derailleur
SHIMANO DEORE RD-M5100 DIRECT ATTACH 11-SPEED
BB
BSA THREADED 68/73MM
Chain
KMC X11-1
Pedal
ALLOY CAGE PEDAL W/ REFLECTOR
Cockpit
Saddle
ENTITY VOID SADDLE, ø 7mm
Seatpost
TRANZX DROPPER 150MM (27.5") / 170MM (29"), DXL: 30.9 x 459 (27.5") / 499MM (29")
Handlebar
ENTITY XPERT, ALLOY, W: 780MM, BB: 31.8MM, R/D: 30MM, B: 6DEGREE
Handlestem
ENTITY XPERT, ALLOY, E: 40MM, B: 31.8MM, R/D: 7DEGREE
Headset
THREADLESS ZERO STACK HEADSET, ZS 44/28.6 | ZS 56/40
Wheel & Tire
Wheel Set
ALLOY DOUBLE WALL
Wheel Size
27.5" / 29"
Tire
SCHWALBE NOBBY NIC PERFORMANCE 27.5"x2.25" / 29"x2.25"
Rim
ALLOY DOUBLE WALL 584 / 622-30 32H FOR TYRE 584 / 622-54/76
Hub
F: SHIMANO HB-MT400 THRU AXLE 15x100mm 32H CENTER LOCK / R: SHIMANO FH-MT400 THRU AXLE 12X148mm 32H CENTER LOCK
Brake
Brake Lever
SHIMANO MT200 HYDRAULIC DISC BRAKE
Brake Caliper
SHIMANO MT200 HYDRAULIC DISC BRAKE
Rotor
ROTOR: FRONT:180MM REAR:160MM CENTER-LOCK
