Specification
The specifications, colors, parts, and availability of the products can be subjects to alter without prior notification.
Frameset
Frame
ALX TRAIL FRAME 140MM TRAVEL (27.5”) / 135MM TRAVEL (29”), TAPER H/T
Fork
ROCKSHOX RECON RL BOOST 15X110MM, 150MM (27.5”) / 140MM (29”) TRAVEL
Rear Shock
ROCKSHOX DELUXE PLUS SELECT SPECIAL TUNING E2E:210X55MM, HARDWARE:8MMX25MM
Frame Color
MAXIMUM BLUE GREEN - LIME
Decal Color
BLUE GREEN - SHEEN GREEN - BLACK
Drivetrain
Shifter
SHIMANO DEORE SL-M6100-R, 1x12-SPEED TRIGGER
Crank
12 SPEED 11-51T
Cassette
SHIMANO DEORE CS-M6100 10-51T MICROSPLINE
Rear Derailleur
SHIMANO DEORE RD-M6100-SGS DIRECT ATTACH
BB
SHIMANO 2-PIECE CRANKSET BSA THREADED
Chain
KMC X12 12SPEED
Pedal
-
Cockpit
Saddle
ENTITY XTEND
Seatpost
TRANZ-X JD-YSP23JL 150mm (S, M) / 170mm TRAVEL (L, XL)
Handlebar
ENTITY XPERT, ALLOY W:780MM R:20MM BB:35MM
Handlestem
ENTITY XPERT, ALLOY E:35MM R:7DEG BB:35MM
Headset
ZERO STACK (ZS) SEALED BEARING FOR TAPER HEAD TUBE, ZS 44/28.6 | ZS 56/40
Wheel & Tire
Wheel Set
ENTITY XL2 DISC
Wheel Size
27.5" / 29"
Tire
PERFORMANCE TIRE, 27.5”X2.40” / 29”X2.40”
Rim
584 / 622-35 32H FOR TYRE 584 / 622-54/76 TUBELESS READY
Brake
Brake Caliper
TEKTRO HD-M735 HYDRAULIC DISC BRAKES
Rotor
SHIMANO SM-RT54 180mm CENTER-LOCK
